- 6X zoom. Low power for greater Field of View; high power for greater detail and identification. 30mm central tube.
- Patented 4-point coil spring system for ultimate reliability, holds zero absolutely and absorbs recoil shock to scope.
- Extended eye relief for more comfort and safety.
- Eye relief increased from 95mm to 120mm.
- Ultra-precise adjustment turrets and guaranteed shock resistance, even for large caliber rifles.
Product Description
Compact and rugged, the Z3 3-10x42 Riflescope from Swarovski upgrades the time-tested AV-Line of scopes--offering high-precision optics in a streamlined model that is well suited to many hunting situations. Due to its shapely design, the Z3 3-10x42 can fit with a range of guns --with slim construction that allows it mount close to the barrel. This riflescope comes ready to shoot with a Plex aiming reticle and carries a limited lifetime warranty from Swarovski.
Amazon.com
Compact and rugged, the Z3 3-10x42 Riflescope from Swarovski upgrades the time-tested AV-Line of scopes--offering high-precision optics in a streamlined model that is well suited to many hunting situations. Due to its shapely design, the Z3 3-10x42 can fit with a range of guns--with slim construction that allows it mount close to the barrel. This riflescope comes ready to shoot with a Plex aiming reticle and carries a limited lifetime warranty from Swarovski.
Optical System Features:
- 3x zoom in a 1-inch scope
- Large 6.3 to 2.2 degree field of view
- Centered reticle in the second image plane
- Rapid diopter adjustment
- Microstructure surface: precisely defined ribbing to prevent residual reflections inside the tube for bright, high-contrast images, even in intense light
- Improved anti-reflective lens coatings deliver the highest optical performance in all light conditions
The riflescope features a Plex aiming reticle. Key Function and Design Features:- Main Tube: The rugged, one-inch, lightweight alloy main tube is finished with a tough anodized scratch resistant surface. The slim tube provides enough space for easy mounting.
- Turrets: Large, rugged turrets feature distinctive adjustable clicks for accurate adjustments. The turrets are waterproof even when the turret caps removed.
- Reticle Adjustment: The scope offers a wide range of adjustment for easy sighting in with precise adjustment of the reticle--shot after shot. The zero setting system offers precision adjustment of the point of impact without the use of tools.
- Magnification Ring: The soft, wide ribbed magnification ring features a sure grip for accurate adjustment and allows quick adjustment of entire magnification range.
- Eye Relief: The long 3.54 inch eye relief allows for comfortable concentration on the shot.
Technical Specifications
- Magnification: 3.3 to 10x
- Objective lens: 42 millimeters
- Exit pupil: 12.6 to 4.2 millimeters
- Exit pupil distance: 90 millimeters / 3.54 inches
- Field of view: 11 to 3.9 meters at 100 meters / 33-11.7 feet at 100 yards
- Field of view: 6.3 to 2.2 degrees
- Subjective field of view, apparent: 22.7 degrees
- Dioptric compensation (diopter): 2, 5
- Transmission (percent):>90
- Impact point cord. per click: 7 millimeters at 100 meters / 0.25 inches at 100 yards
- Maximum elevation/windage adjustment range: 1.4 meters at 100 meters / 50 inches at 100 yards
- Parallax correction: 109
- Objective filter thread: M 44 x 0.75
- Length (approximate): 321 millimeters / 12.64 inches
- Weight (approximate): 360 grams / 12.7 ounces
- Central tube diameter: 1 inch
